| IP Rating | Warranty | Watts | Input Voltage | CRI | Beam Angle | Housing Material | Ambient Temperature | Mounting |
|---|---|---|---|---|---|---|---|---|
| IP20 | ≥5 Years | 20~60W | AC 220-240V | 80+ | 120° | AL6063 | 0℃ ~ 40℃ | Recessed |
| Item Code | Description | Power (W) | Lumen Output(LM) | CCT(K) | Dimensions(mm) | Weight(KG) | Dimmable |
|---|---|---|---|---|---|---|---|
| LL06-0734022D1PCD050 | 500mm 16W 90lm/W 4000K | 16 | 1440 | 4000 | 524X120X93 | 0.6 | No |
| LL06-0324022D1PCD080 | 800mm 32W 90lm/W 4000K | 32 | 2880 | 4000 | 824X120X93 | 1.0 | No |
| LL06-0404022D1PCD100 | 1000mm 40W 90lm/W 4000K | 40 | 3600 | 4000 | 1024X120X93 | 1.2 | No |
| LL06-0504022D1PCD120 | 1200mm 50W 90lm/W 4000K | 50 | 4500 | 4000 | 1224X120X93 | 1.8 | No |
| * Colour temperatures available 2700K, 3000K, 3500K, 4000K, 5000K, 6500K * 1-10V, DALI dimming options is available | |||||||
