| IP Rating | Warranty | Watts | Input Voltage | CRI | Beam Angle | Housing Material | Ambient Temperature | Mounting |
|---|---|---|---|---|---|---|---|---|
| IP20 | ≥5 Years | 20~60W | AC 220-240V | 80+ | 120° | AL6063 | 0℃ ~ 40℃ | Recessed&Suspended |
| Item Code | Description | Power(W) | Lumen Output(LM) | CCT(K) | Dimensions(mm) | Weight(KG) | Dimmable |
|---|---|---|---|---|---|---|---|
| LL03-040403A | TYPE3A W90XH50 | 40 | 3600 | 4000 | 1200X90X50 | 4.0 | No |
| LL03-040403B | TYPE3B W95XH50 Recess | 40 | 3600 | 4000 | 1200X95X50 | 4.2 | No |
| LL03-040204A | TYPE4A W45XH30 | 20 | 1800 | 4000 | 1200X45X30 | 2.5 | No |
| LL03-040204B | TYPE4B W55XH30 Recess | 20 | 1800 | 4000 | 1200X55X30 | 2.6 | No |
* Colour temperatures available 2700K, 3000K, 3500K, 4000K, 5000K, 6500K * 1-10V, DALI dimming options is available | |||||||
