| IP Rating | Warranty | Watts | Input Voltage | CRI | Beam Angle | Housing Material | Ambient Temperature | Mounting |
|---|---|---|---|---|---|---|---|---|
| IP20 | >5 Years | 20~60W | AC 220-240V | 80+ | 120° | Cold Rolled Steel | 0℃ ~ 40℃ | Recessed, Suspended, Wall mounted & Surface mounted |
| Item Code | Description | Power (W) | Lumen Output(LM) | CCT(K) | Dimensions(mm) | Weight(KG) | Dimmable |
|---|---|---|---|---|---|---|---|
| LL02-0734022D1PCD390 | 3900mm 73W 90lm/W 4000K | 73 | 6570 | 4000 | 3900X50X67 | 9.8 | No |
| LL02-0564022D1PCD300 | 3000mm 56W 90m/W 4000K | 56 | 5040 | 4000 | 3000X50X67 | 7.5 | No |
| LL02-0394022D1PCD210 | 2100mm 39W 90lm/W 4000K | 39 | 3510 | 4000 | 2100X50X67 | 5.2 | No |
| LL02-0284022D1PCD150 | 1500mm 28W 90lm/W 4000K | 28 | 2520 | 4000 | 1500X50X67 | 3.8 | No |
| LL02-0224022D1PCD120 | 1200mm 22W 90m/W 4000K | 22 | 1980 | 4000 | 1200X50X67 | 3 | No |
| LL02-0174022D1PCD090 | 900mm 17W 90Im/W 4000K | 17 | 1530 | 4000 | 900X50X67 | 2.3 | No |
| LL02-0134022D1PCD060 | 600mm 13W 90lm/W 4000K | 13 | 1170 | 4000 | 600X50X67 | 1.5 | No |
| * Colour temperatures available 2700K, 3000K, 3500K, 4000K, 5000K, 6500K * 1-10V, DALI dimming options is available | |||||||
