| IP Rating | Warranty | Watts | Input Voltage | CRI | Beam Angle | Housing Material | Ambient Temperature | Mounting |
|---|---|---|---|---|---|---|---|---|
| IP66 | 5 Years | 20-100W | AC 220-240V | 80+ | 120° | PC | -20℃ ~ 40℃ | Surface |
| Item Code | Description | Power(W) | Efficiency(lm/w) | CCT(K) | Dimensions LxWxH(mm) | Weight(KG) |
|---|---|---|---|---|---|---|
| LIF-BT12F2DDEE | Vandaproof BT12 30W 2FT | 32W/27W/23W/18W | 110 | 4000 | 700X137X83 | 2.6 |
| LIF-BT12F2DDEED | Vandaproof BT12 30W 2FT+Sensor | 32W/27W/23W/18W | 110 | 4000 | 700X137X83 | 2.8 |
| LIF-BT12F2DDEE/ME | Vandaproof BT12 30W 2FT+Emergency | 32W/27W/23W/18W | 110 | 4000 | 700X137X83 | 3.3 |
| LIF-BT12F4DDEE | Vandaproof BT12 60W 4FT | 62W/57W/53W/49W | 110 | 4000 | 1308X137X83 | 4.7 |
| LIF-BT12F4DDEED | Vandaproof BT12 60W 4FT+Sensor | 62W/57W/53W/49W | 110 | 4000 | 1308X137X83 | 4.9 |
| LIF-BT12F4DDEE/ME | Vandaproof BT12 60W 4FT+Emergency | 62W/57W/53W/49W | 110 | 4000 | 1308X137X83 | 5.4 |
Suffix “DD” can be 27, 30, 35, 40, 45, 50, 57, 65, indicating the different CCT multiply by 100 in K. Suffix “EE” can be 80, 85, 90, 95, indicating the different CRI of LED. | ||||||
