TF22
■ IK08 and IP40 level for special applications ■ Efficiency up to 137lm/W ■ 0.7mm Cold-rolled steel body, finished in white polyester powder coating ■ Excellent prismatic diffusor provides an even light output, and UGR<22 ■ Two types of installation accessories optional: recessed mounting frame or chain suspension ■ DALI Dimming as a standard ■ Optional sensor function / emergency function available
Consult
  • General Specifications
    IP RatingWarrantyWattsInput VoltageFrequency RangeCRIBeam AngleHousing MaterialAmbient TemperatureMounting
    IP40>5 Years58～146W220-240Vac50/60Hz80+90°Cold Rolled Steel-20℃ ~ 40℃Suspended / Recessed / Surface mounting
  • Dimensions


  • Technical Data
    Item Code

    Dimensions LxWxH (mm)

    		PowerColour TemperatureLuminous EfficiencyLumen Output(LM)Gross Weight(KG)Dimming
    LIF-SP58W1540x315x9558W4000K
    		137 lm/w800013.8DALI
    LIF-SP88W1540x315x9588W4000K137 lm/w1200013.8DALI
    LIF-SP117W1540x415x95117W4000K137 lm/w1600016.7DALI
    LIF-SP146W1540x415x95146W4000K137 lm/w2000016.7DALI
    * Colour temperatures available 2700K, 3000K, 3500K, 4000K, 5000K, 6500K
