TF08
■ Both Options for UGR19 or UGR22 ■ IP54 from below and IP40 from above ■ Sheet steel construction with highly reflective textured powder painting ■ High efficiency125lm/w ■ Designed for a standard T-Bar grid, also suitable for plaster ceilings by using plaster master frames ■ Available at 600x600mm, 1200x600mm & 1200x300mm and customized size ■ Non-dim and DALI as standard. Various control options are available via customization ■ Emergency or sensor options available ■ Air ventilation slot available
Consult
  • General Specifications
    IP RatingWarrantyWattsInput VoltageFrequency RangeCRIBeam AngleHousing MaterialAmbient TemperatureMounting
    IP40>5 Years10~45W220-240Vac50/60Hz80+100°Cold Rolled Steel-20℃ ~ 40℃Recessed
  • Dimensions


  • Item CodeDimensions L x W x H (mm)Power ConsumptionColour TemperatureCRILuminous EfficiencyLumen Output(LM)Weight(KG)

    LIF-TF08BB063DDEEFF

    		595x295x62

    10W

    12W

    14W

    17W

    26W

    30W

    35W

    40W

    45W

    		4000K
    		80+125 lm/w

    1250

    1500

    1750

    2100

    3200

    3700

    4300

    5000

    5600

    		    2.3

    LIF-TF08BB066DDEEFF

    		595x595x62

    10W

    12W

    14W

    17W

    26W

    30W

    35W

    40W

    45W

    		4000K80+125 lm/w

    1250

    1500

    1750

    2100

    3200

    3700

    4300

    5000

    5600

    		    4.3

    LIF-TF08BB123DDEEFF

    		1195x295x62

    10W

    12W

    14W

    17W

    26W

    30W

    35W

    40W

    45W

    		4000K80+125 lm/w

    1250

    1500

    1750

    2100

    3200

    3700

    4300

    5000

    5600

    		    4.6

    LIF-TF08BB126DDEEFF

    		1195x595x62

    10W

    12W

    14W

    17W

    26W

    30W

    35W

    40W

    45W

    		4000K80+125 lm/w

    1250

    1500

    1750

    2100

    3200

    3700

    4300

    5000

    5600

    		    8.1

    Suffix “DD” can be 27, 30, 35, 40, 45, 50, 57, 65, indicating the different CCT multiply by 100 in K.

    Suffix “EE” can be 80, 85, 90, 95, indicating the different CRI of LED.

    Suffix “FF” can be 19, 22, indicating the different UGR of light.
