Sky Simulator
■ Using rayleigh scattering theory to simulate the blue sky ■ It's slim frame, easy to install in a plaster ceiling ■ Good heat dissipation can be well used as the main lighting product ■ Access to all kinds of function system to achieve a healthy lighting environment
  • Characteristic
    Why is the sky so blue - Rayleigh scatteringSky lamp featuresInnovative functional design of sky lamps
    We have developed this product using the latest technology and materials. By combining materials science and optics and utilizing the principle of Rayleigh scattering, we have created an optical panel that can strongly scatter the blue and violet light in white light. This solves the problem of developing materials for sky lamps and promotes new applications for healthy lighting!

    Ultra-thin, with no blue light hazard characteristics, can be directly replaced or installed using the existing ceiling keel system.

    Main lighting fixture use: Good heat dissipation design can be used as the main lighting fixture.

    Modern lighting has surpassed the traditional concept of environmental lighting. Sky lamps have gradually developed towards functionalization. Customers can install ventilation systems, Wi-Fi devices, auxiliary lighting systems, gas sensors, security monitoring systems, etc., through modular design according to the needs of the application scenarios, to achieve functional environmental lighting.
  • Application






  • Dimensions



  • Technical Data
    Item CodePower(w)Dimension(mm)Cutting Size(mm)InstallationWeight(KG)
    TF14A0664

    70

    597x597x102498x498Recessed, Suspension6.0
    TF14A1234701197x297x1021098x198Recessed, Suspension6.0
    TF14A12641001197x597x1021098x498Recessed, Suspension9.0
