IP Rating | Warranty | Watts | Input Voltage | CRI | Beam Angle | Housing Material | Ambient Temperature | Mounting |
---|---|---|---|---|---|---|---|---|
IP20 | >5 Years | 20-60W | AC 220-240V | 80+ | 120° | Cold Rolled Steel | -20℃ ~ 40℃ | Surface Mounted |
Item Code | Description | Power Selectable (W) | Efficiency(lm/w) | CCT(K) (3 Levels) | Dimensions(mm) | Weight(KG) |
---|---|---|---|---|---|---|
LIF-BT05BB2DDEE | BT05 20W 2FT Color Selectable | 20W/17W/14W/10W | 130 | 2700-6500 | 603X120X72 | 1.1 |
LIF-BT05BB2DDEED | BT05 20W 2FT Color Selectable+Sensor | 20W/17W/14W/10W | 130 | 2700-6500 | 603X120X72 | 1.3 |
LIF-BT05BB2DDEE/ME | BT05 20W 2FT Color Selectable +EM | 20W/17W/14W/10W | 130 | 2700-6500 | 603X120X72 | 1.7 |
LIF-BT05BB4DDEE | BT05 40W 4FT Color Selectable | 40W/30W/26W/23W | 130 | 2700-6500 | 1166X120X72 | 2.0 |
LIF-BT05BB4DDEED | BT05 40W 4FT Color Selectable+Sensor | 40W/30W/26W/23W | 130 | 2700-6500 | 1166X120X72 | 2.1 |
LIF-BT05BB4DDEE/ME | BT05 40W 4FT Color Selectable+ EM | 40W/30W/26W/23W | 130 | 2700-6500 | 1166X120X72 | 2.5 |
LIF-BT05BB5DDEE | BT05 60W 5FT Color Selectable | 60W/50W/45W/40W | 130 | 2700-6500 | 1500X120X72 | 2.3 |
LIF-BT05BB5DDEED | BT05 60W 5FT Color Selectable+Sensor | 60W/50W/45W/40W | 130 | 2700-6500 | 1500X120X72 | 2.5 |
LIF-BT05BB5DDEE/ME | BT05 60W 5FTColor Selectable+ EM | 60W/50W/45W/40W | 130 | 2700-6500 | 1500X120X72 | 2.9 |
Suffix “DD” can be 27, 30, 35, 40, 45, 50, 57, 65 or CS, indicating the different CCT of LED multiply by 100 in K, CS means white-tunable over a range of 2700K-6500K. Suffix “EE” can be 80, 85, 90, 95, indicating the different CRI of LED. |
