IP Rating | Warranty | Watts | Input Voltage | CRI | Beam Angle | Housing Material | Ambient Temperature | Mounting |
---|---|---|---|---|---|---|---|---|
IP20 | >5 Years | 18-50W | AC 220-240V | 80+ | 120° | Cold Rolled Steel | -20℃ ~ 40℃ | Surface&Supended |
Item Code | Description | Power Selectable(W) | Efficiency(lm/w) | CCT(K) (3 Levels) | Dimensions(mm) | Weight(KG) |
---|---|---|---|---|---|---|
LIF-BT09BB2DDEE | BT09 20W 2FT Color Selectable | 18W | 130 | 2700-6500 | 600X60X60 | 0.6 |
LIF-BT09BB2DDEED | BT09 20W 2FT Color Selectable+Sensor | 18W | 130 | 2700-6500 | 600X60X60 | 0.7 |
LIF-BT09BB2DDEE/ME | BT09 20W 2FT Color Selectable +EM | 18W | 130 | 2700-6500 | 600X60X60 | 1.0 |
LIF-BT09BB4DDEE | BT09 40W 4FT Color Selectable | 36W/30W/25W/20W | 130 | 2700-6500 | 1164X60X60 | 1.3 |
LIF-BT09BB4DDEED | BT09 40W 4FT Color Selectable+Sensor | 36W/30W/25W/20W | 130 | 2700-6500 | 1164X60X60 | 1.4 |
LIF-BT09BB4DDEE/ME | BT09 40W 4FT Color Selectable+ EM | 36W/30W/25W/20W | 130 | 2700-6500 | 1164X60X60 | 1.7 |
LIF-BT09BB5DDEE | BT09-50W 5FT Color Selectable | 50W/45W/35W/30W | 130 | 2700-6500 | 1500X60X60 | 1.6 |
LIF-BT09BB5DDEED | BT09 50W 5FT Color Selectable+Sensor | 50W/45W/35W/30W | 130 | 2700-6500 | 1500X60X60 | 1.7 |
LIF-BT09BB5DDEE/ME | BT09 50W 5FTColor Selectable+ EM | 50W/45W/35W/30W | 130 | 2700-6500 | 1500X60X60 | 2.0 |
Suffix “DD” can be 27, 30, 35, 40, 45, 50, 57, 65 or CS, indicating the different CCT of LED multiply by 100 in K, CS means white-tunable over a range of 2700K-6500K. Suffix “EE” can be 80, 85, 90, 95, indicating the different CRI of LED. |
